Electric Chain Hoists
We sell electric chain hoist with 1-5 ton lifting capacity, lifting height of 3-9 meters, used as lifting unit in monorail cranes, overhead and gantry cranes. Hoists include hoist hook, hoist trolley and electric panel.
| Model | 1 TON | 2 TON | 3 TON | 5 TON | |
|---|---|---|---|---|---|
| LIFTING CAPACITY (ton) | 1 | 2 | 3 | 5 | |
| LIFTING HEIGHT (m) | 3 / 9 | 3 / 9 | 3 / 9 | 3 / 9 | |
| LIFTING SPEED (m/min) | 6.8 | 6.8 | 5.6 / 4.4 | 5.6 / 4.4 | |
| LIFTING UNIT |
POWER (kW) | 1.5 | 3.0 | 3.0 | 3.0 |
| ROTATION SPEED (r/min) | 1440 | 1440 | 1440 | 1440 | |
| PHASE | 3 | 3 | 3 | 3 | |
| VOLTAGE (V) | 380 | 380 | 380 | 380 | |
| FREQUENCY (Hz/s) | 50 | 50 | 50 | 50 | |
| TRAVELING UNIT |
POWER (kW) | 0.4 | 0.4 | 0.4 / 0.75 | 0.4 / 0.75 |
| ROTATION SPEED (r/min) | 1440 | 1440 | 1440 | 1440 | |
| TRAVELING SPEED (m/min) | 10/20 | 10/20 | 10/20 - 11/21 | 10/20 - 11/21 | |
| PHASE | 3 | 3 | 3 | 3 | |
| VOLTAGE (V) | 380 | 380 | 380 | 380 | |
| CHAIN TYPE | Single | Single / Double | |||
| HOOK BLOCK | Single Roller | Single Roller / Double Roller | |||
