2 Tons Electric Chain Hoist
2 ton lifting capacity, 3-9 meters lifting height, used as a lifting unit for monorail cranes, overhead cranes and gantry cranes. Hoist hook, hoist trolley and electric panel are included in our chain hoists.
Technical Specifications
| Model | 2 TON | |
|---|---|---|
| LIFTING CAPACITY (ton) | 2 | |
| LIFTING HEIGHT (m) | 3 / 9 | |
| LIFTING SPEED (m/min) | 6.8 | |
| LIFTING UNIT |
POWER (kW) | 3.0 |
| ROTATION SPEED (r/min) | 1440 | |
| PHASE | 3 | |
| VOLTAGE (V) | 380 | |
| FREQUENCY (Hz/s) | 50 | |
| TRAVELING UNIT |
POWER (kW) | 0.4 |
| ROTATION SPEED (r/min) | 1440 | |
| TRAVELING SPEED (m/min) | 10/20 | |
| PHASE | 3 | |
| VOLTAGE (V) | 380 | |
| CHAIN TYPE | Single | |
| HOOK BLOCK | Single Roller | |
How to Order
For ordering, first determine whether you need normal and slow double speed according to the material you will lift and carry. Our sales team will offer you the most suitable 2-ton electric chain hoist price.
