180 Degree Jib Cranes
The 180 degree jib crane lifting unit moves forward and backward on the main arm, and also performs moving operations with the right and left rotating motion and alternatively works in two different speed modes. Generally, the used speed mode is normal speed mode and is suitable for many applications. It also works in slow mode for precise lifting and handling. 180 degree jib cranes; It is widely used in mechanical production workshops, product assembly line, warehouse and cargo areas. Control can be done by manual control or remote control.
Technical Specifications
| LIFTING CAPACITY (ton) | 1 | 2 | 3 | 5 |
|---|---|---|---|---|
| LIFTING HEIGHT (m) | 3-4 | |||
| LIFTING SPEED (m/min) | 8 / 0.8 | |||
| TRAVELING SPEED (m/min) | 20 | |||
| POWER SUPPLY | 380 V, 3 FAZ, 50 Hz | |||
| CONTROL TYPE | Manual / Remote Controller | |||
How to Order
Specify your lifting capacity and lifting height requirement for the order first. Determine whether you need normal and slow double speed according to the material you will lift and transport. Once you have determined the radius of the area where the 180 degree jib crane will work, call us. Our expert team will recommend the most suitable 180 degree jib crane system for you.
