1 Ton Ex-Proof Electric Hoists
1 ton lifting capacity, 9 meters lifting height used as lifting units are used in monorail, bridge and gantry cranes. Our Ex-Proof electric winches include hoist hook, hoist trolley and electric panel.
Technical Specifications
| Model | 1 TON | |
|---|---|---|
| LIFTING CAPACITY (ton) | 1 | |
| ROPE THICKNESS (mm) | 8 | |
| LIFTING HEIGHT (m) | 9-30 | |
| LIFTING SPEED MODE | Double Speed / Single Speed | |
| LIFTING SPEED (m/min) | 8 / 0.8 | |
| TRAVELING SPEED (m/min) | 20 | |
| LIFTING UNIT |
POWER (kW) | 1.5 |
| ROTATION SPEED (r/min) | 1380 | |
| PHASE | 3 | |
| VOLTAGE (V) | 380 | |
| FREQUENCY (Hz/s) | 50 | |
| TRAVELING UNIT |
POWER (kW) | 0.2 |
| ROTATION SPEED (r/min) | 1380 | |
| PHASE | 3 | |
| VOLTAGE (V) | 380 | |
| FREQUENCY (Hz/s) | 50 | |
| HOOK BLOCK | 2/1 | |
| CONTROL TYPE | Pendant / Remote Controller (optional) | |
How to Order
For ordering, first determine whether you need normal and slow double speed according to the material you will lift and carry. Our sales team will offer you the best price for 1 ton ex-proof electric hoist.
